MF-15-K
6,95 €
°C
Room temperature sensor in the surface switch program THERMASGARD® FSTF1 LM235Z
THERMASGARD® FSTF1 LM235Z
SKU 1101-5022-1000-162
EAN 4 251325 604145
Product group: WG01
In stock
, available in 3-5 working days
Shipping calculated at checkout.
Regular price
57,89 €
Regular price
Sale price
57,89 €
Consegna in 2 giorni in Italia
Garanzia di 5 anni
Richiedi uno sconto quantità
Product description
- passive
- –30...+60 °C
- 2-wire connection
The THERMASGARD room sensor connection diagram FSTF - xx ® FSTF is used for air temperature measurement or setpoint adjustment, presence detection or as a room control unit, as a control panel with temperature sensor, buttons, potentiometer, status indicators (LED).
The flush-mounted sensor is installed in high-quality surface switch programs, preferably from Gira, Berker, Merten, Jung, Siemens or Busch-Jaeger (using flush-mounted adapters), either individually or in combination with light switches, sockets, etc.
It is used in non-aggressive, dust-free environments, in refrigeration, air conditioning and clean room technology, in interiors such as living rooms, offices, hotels, etc.
The flush-mounted sensor is installed in high-quality surface switch programs, preferably from Gira, Berker, Merten, Jung, Siemens or Busch-Jaeger (using flush-mounted adapters), either individually or in combination with light switches, sockets, etc.
It is used in non-aggressive, dust-free environments, in refrigeration, air conditioning and clean room technology, in interiors such as living rooms, offices, hotels, etc.
Technical data
| Sensor | LM235Z |
| Function type | Measuring temperature |
| Measured variables | Temperature, passive temperature |
| Display | No |
| IP protection class | IP20 |
| Output variant | - |
| Housing | GIRA System 55 |
| Measuring range | -30...+60 °C |
