WS-01
36,10 €
°C
Room temperature controller THERMASREG® RTR-B 121
THERMASREG® RTR-B 121
SKU 1102-4011-2100-000
EAN 4 251325 609768
Product group: WG01
In stock
, available in 1-3 working days
Shipping calculated at checkout.
Regular price
42,94 €
Regular price
Sale price
42,94 €
Consegna in 2 giorni in Italia
Garanzia di 5 anni
Richiedi uno sconto quantità
Product description
- Heating, external setpoint
- Control range: +5...+30 °C
- Switching capability:
230 V AC, 50 - 60 Hz
Heating: 10 mA...10 (4) A, DC 30 W
Cooling: 10 mA...5 (2) A - Switching differential: approx. 0.5 K
- Sensing element: bimetal
- Output: normally open
- IP30
Single-stage, mechanical individual room controller THERMASREG® RTR - B in bi-metal technology, with thermal feedback, suitable for temperature monitoring or control in dry rooms or for controlling all types of heating systems, as a room thermostat.
The cooling output of the changeover contact (NO contact) must be connected for normally open radiator valves. A maximum of 10 valve actuators can be connected to the NC contacts and a maximum of 5 to the NO contact.
The cooling output of the changeover contact (NO contact) must be connected for normally open radiator valves. A maximum of 10 valve actuators can be connected to the NC contacts and a maximum of 5 to the NO contact.
Technical data
| Measured values | Temperature |
| IP protection rating | IP30 |
| Output | Normally open |
